Creality Ender-5 Max 3D Printer – Large 400×400×400 mm Volume, Auto-Leveling & Direct Drive Extruder

The Creality Ender-5 Max is a large-format FDM 3D printer built for creators, engineers, and hobbyists who demand precision and volume. With a massive 400×400×400 mm print area, direct drive extruder, and 36-point auto bed leveling, it ensures consistent results across a wide range of filament types including flexible TPU95A, PLA-CF, ABS, ASA, and PA.

Engineered for high-speed, high-precision printing with acceleration up to 20,000 mm/s² and speeds of up to 700 mm/s, the Ender-5 Max combines power and convenience. The flexible epoxy build plate, 4.3” color touchscreen, and G-Code support through USB, Wi-Fi, or Creality Cloud make it ready for any task.

With features like filament runout detection, power recovery, sleep mode, and lighting kit, this printer is built for reliable, uninterrupted 3D printing—whether in a workshop, lab, or studio.

Key Features:

• Build volume: 400 × 400 × 400 mm

• Print speed: up to 700 mm/s

• Auto-leveling: 36-point system

• Direct drive extruder with 0.4 mm nozzle (0.6/0.8 mm compatible)

• Filament support: Hyper PLA, PETG, TPU95A, ABS, ASA, PLA-CF, PA, PLA-Silk

• 4.3" color touchscreen, flexible epoxy platform

• File transfer via USB, Wi-Fi, or Creality Cloud app

• Advanced functions: power loss recovery, filament sensor, LED lighting, sleep mode

Technical Specifications – Creality Ender-5 Max

• Manufacturer: Creality

• Model: Ender-5 Max

• Printing Technology: FDM (Fused Deposition Modeling)

• Build Volume: 400 × 400 × 400 mm

• Printer Dimensions: 649 × 721 × 850 mm

• Weight: ≤ 25.9 kg

• Max Print Speed: ≤ 700 mm/s

• Acceleration: ≤ 20,000 mm/s²

• Print Accuracy: 100 ± 0.1 mm

• Layer Height: 0.05 – 0.3 mm

• Extruder Type: Direct Drive

• Filament Diameter: 1.75 mm

• Nozzle Diameter: 0.4 mm (compatible with 0.6 / 0.8 mm)

• Max Nozzle Temp: ≤ 300°C

• Max Bed Temp: ≤ 100°C

• Build Surface: Flexible epoxy plate

• Bed Leveling: 36-point auto leveling

• Status Light Indicator: Red / Green / Yellow

• File Transfer: USB, Wi-Fi

• Display: 4.3-inch color touchscreen

• Camera: Optional

• Power Loss Recovery: Yes

• Filament Runout Sensor: Yes

• Signal Input Shaping: Yes

• Lighting Kit: Included

• Sleep Mode: Yes

• Input Voltage: 100–240 V AC, 50/60 Hz

• Rated Power: 1250 W

• Operating Temperature: 5°C – 40°C

• Supported Filaments: Hyper PLA, PLA, PETG, TPU95A, ABS, ASA, PLA-CF, PA, PLA-Silk

• Print File Format: G-Code

• Slicer Software: Creality Print 5.1

• Supported File Types: STL, OBJ, 3MF

• Cloud App: Creality Cloud

• Interface Languages: English, Spanish, German, French, Russian, Portuguese, Italian, Turkish, Japanese, Korean, Chinese
